| NOMINAL DIAMEETER | OUTSIDE DIAMEETER | TYPE (A) WALL THIKNESS | TYPE (B) WALL THIKNESS | |||
|---|---|---|---|---|---|---|
| Min | Max | Min | Max | Min | Max | |
| 40 | 40 | 40.3 | 1.8 | 2.2 | 3.2 | 3.8 |
| 50 | 50 | 50.3 | 1.8 | 2.2 | 3.2 | 3.8 |
| 63 | 63 | 60.3 | 1.8 | 2.2 | 3.2 | 3.8 |
| 75 | 75 | 75.3 | 1.8 | 2.2 | 3.2 | 3.8 |
| 90 | 90 | 90.3 | 1.9 | 2.3 | 3.2 | 3.8 |
| 110 | 110 | 110.4 | 2.2 | 2.7 | 3.2 | 3.8 |
| 125 | 125 | 125.4 | 2.5 | 3 | 3.2 | 3.8 |
| 140 | 140 | 140.5 | 2.9 | 3.4 | 3.6 | 4.2 |
| 160 | 160 | 160.5 | 3.2 | 3.8 | 4 | 4.6 |
| 180 | 180 | 180.6 | - | - | 4.6 | 5.5 |
| 200 | 200 | 200.6 | - | - | 4.9 | 5.6 |
| . | PIPES | FITTINGS |
|---|---|---|
| SIZES | 75MM, 90MM, 110MM, 160MM | 75MM, 110MM, 160MM |
| REFERENCE STANDARDS | IS 13592: 2013 | IS 14735 |
| COLOR | LIGHT GREY | LIGHT GREY |
| MATERIALS | Unplasticized Polyvinyl Chloride(UPVC) | Unplasticized Polyvinyl Chloride(UPVC) |
